17 System mode ADVANCED
17.2.5.1.2 AlarmOutput
NOTICE
▶ Certain Active Levels are required (see “Activating or deactivating user access“, page47) in order to read and edit the para-
meters.
Submenu for setting the alarm outputs
Display Function Value range Default setting Active level
Read Edit
Alarm Fn Defines the function
of the alarm output
OFF
Min / max
Min / min
Max / max
OFF 0 2
Level Alarm 1 Switch point of alarm
1
0.0...100.0% 10.0% 0 1
Level Alarm 2 Switch point of alarm
2
0.0...100.0% 90.0% 0 1
17.2.5.1.3 ErrorOutput
NOTICE
▶ Certain Active Levels are required (see “Activating or deactivating user access“, page47) in order to read and edit the para-
meters.
Submenu for setting the error output
Display Function Value range Default setting Active level
Read Edit
Error Functn Defines the function of
the
error message output
Error
Error+Inactive
Range
ERROR + RANGE
Err+Range+Inac
ERROR + RANGE 0 3
Error Time Valve travel time
monitoring
AUTO
0.0...100.0 s
AUTO 0 3
Error Level Maximum
system deviation
AUTO
0.0...100.0%
AUTO 0 3
Range Functn Range monitoring of set
value input
< 4 mA
> 20 mA
< 4 mA or > 20 mA
< 4 mA or > 20 mA 0 3
17.2.5.1.4 PositionOutput
NOTICE
▶ Certain Active Levels are required (see “Activating or deactivating user access“, page47) in order to read and edit the para-
meters.
Submenu for setting the actual value output
Display Function Value range Default setting Active level
Read Edit
Analog Out Defines the function of the
actual value output
0–10 V
0–20 mA
1)
4–20 mA
1)
0–10 V 0 2
