4.3 Maximum Power Supply Ratings
60
 ELSxT_HID_v04 2018-09-04
Confidential / Preliminary
Page 55 of 102
I
PLUS
LTE DATA
Band 18, 23dBm
@8V - - - 760 - mA
@30V - - - 210 -
@57V - - - 120 -
LTE DATA
Band 19, 23dBm
@8V - - - 740 - mA
@30V - - - 200 -
@57V - - - 115 -
LTE DATA
Band 20, 23dBm
@8V ----mA
@30V ----
@57V ----
LTE DATA
Band 28, 23dBm
@8V - - - mA
@30V - - -
@57V - - -
1. Lowest voltage (minimum peak) incl. all ripple and drops >7.6V including voltage drop, ripple and spikes,
measured at western jack (6-pole) pins.
2. Typical values measured with antenna impedance = 50 Ohm (return loss >20dB).
Table 24: Power supply specifications
Para-
meter
Description Conditions Typical Unit
ELS61
T-E/E2
ELS61
T-US
ELS61
T-AUS
ELS31
T-J
ELS31
T-V
