4.5 Antenna Interface
Table 26 lists RF antenna interface specifications for the LTE Terminals. Please note that the
specified conditions may not apply to or be supported by all terminals.
Table 26: RF Antenna interface GSM / UMTS / LTE
Parameter Conditions Min. Typical Max. Unit
LTE connectivity Band 1, 2, 3, 4, 5, 8, 12, 13, 18, 19, 20, 28 (not every module variant
supports all bands)
Receiver Input Sensitivity @
ARP, dual antenna (main+
diversity)
LTE 700 Band 12 (ch. band-
width 5MHz)
-99 dBm
LTE 700 Band 13 (ch. band-
width 5MHz)
-99.3 -101 dBm
LTE 700 Band 28 (ch. band-
width 5MHz)
-98.5 dBm
LTE 800 Band 20(ch. band-
width 5MHz)
-97 dBm
LTE 850 Band 5 (ch. band-
width 10MHz)
-98 dBm
LTE 850 Band 18 (ch. band-
width 5MHz)
-99.3 -103 dBm
LTE 850 Band 19 (ch. band-
width 5MHz)
-99.3 -103 dBm
LTE 900 Band 8 (ch. band-
width 5MHz)
-97 dBm
LTE AWS Band 4 (ch. band-
width 10MHz)
-100 dBm
LTE 1800 Band 3 (ch. band-
width 5MHz)
-97 dBm
LTE 1900 Band 2 (ch. band-
width 10MHz)
-100 dBm
LTE 2100 Band 1 (ch. band-
width 5MHz)
-100 dBm
RF Power @ ARP with 50Ω
Load (power supply: 3.8/4V,
temperature 25°C)
LTE 700 Band 12 (ch. band-
width 5MHz; 1RB, position
low)
+23 dBm
LTE 700 Band 13 +23 dBm
LTE 700 Band 28 +23 dBm
LTE 800 Band 20 +23 dBm
LTE 850 Band 5 (ch. band-
width 5MHz; 1RB, position
low)
+23 dBm
LTE 850 Band 18 +23 dBm
LTE 850 Band 19 +23 dBm
LTE 900 Band 8 +23 dBm
