4.5 Antenna Interface
60
 ELSxT_HID_v04 2018-09-04
Confidential / Preliminary
Page 59 of 102
RF Power @
ARP
with 50Ohm
Load,
(with maxi-
mum power
reduction)
GPRS, 1 TX GSM 850 / E-GSM 900 33 dBm
GSM 1800 / GSM 1900 30 dBm
EDGE, 1 TX GSM 850 / E-GSM 900 27 dBm
GSM 1800 / GSM 1900 26 dBm
GPRS, 2 TX GSM 850 / E-GSM 900 30 dBm
GSM 1800 / GSM 1900 27 dBm
EDGE, 2 TX GSM 850 / E-GSM 900 24 dBm
GSM 1800 / GSM 1900 23 dBm
GPRS, 3 TX GSM 850 / E-GSM 900 28.2 dBm
GSM 1800 / GSM 1900 25.2 dBm
EDGE, 3 TX GSM 850 / E-GSM 900 22.2 dBm
GSM 1800 / GSM 1900 21.2 dBm
GPRS, 4 TX GSM 850 / E-GSM 900 27 dBm
GSM 1800 / GSM 1900 24 dBm
EDGE, 4 TX GSM 850 / E-GSM 900 21 dBm
GSM 1800 / GSM 1900 20 dBm
Table 26: RF Antenna interface GSM / UMTS / LTE
Parameter Conditions Min. Typical Max. Unit
