Gemu 1436 cPos - Submenu for setting the digital outputs

36 / 66
1436 cPos
Before a dierent parameter set can be loaded,
it must rst be copied to the appropriate memory
(see chapter 13.3.7 CpyParamSet).
If a digital input (In W, In X, In 1 or In 2) is set to the OFF/
ON or Safe/ON function and the digital signal "High" is not
connected, the following messages will be displayed:
In1noSignal:
The positioner moves to the safe position or is stopped.
In2noSignal:
The positioner moves to the safe position or is stopped.
InWnoSignal:
The positioner moves to the safe position or is stopped.
InXnoSignal:
The positioner moves to the safe position or is stopped.
13.3.5 Settingoutputfunctionsandswitchpoints
DigitalOutput:
Denes the switch conditions for the internal outputs K1 and
K2.
K1Switch:
Denes the output contact type.
NO – make contact or NC – break contact
K1 fn:
Determines the function of output K1.
(no) No function
(P min)
Lower than the valve position preset under
AlarmMinK1
(P max)
Exceeds the valve position preset under
AlarmMaxK1
(P min/max)
Lower or higher than the preset valve
positions
(W min)
Lower than the set value preset under
AlarmMinK1
(W max)
Exceeds the set value preset under
AlarmMaxK1
(W min/max) Lower or higher than the preset set value
(X min)
Lower than the actual value preset under
AlarmMinK1
(X max)
Exceeds the actual value preset under
AlarmMaxK1
(X min/max) Lower or higher than the preset actual value
(SSE min)
Lower than the system deviation preset
under AlarmMinK1
(SSE max)
Exceeds the system deviation preset under
AlarmMaxK1
(SSE min/
max)
Lower or higher than the preset actual value
Active Active if the positioner is in the OFF-mode
Error Error message
Warning Warning message
AlarmMinK1:
Sets the switch point in % under which output K1 is switched.
AlarmMaxK1:
Sets the switch point in % over which output K1 is switched.
SSE1Time:
Determines the delay time for output K1 between error
recognition and error message for a permanent system
deviation.
K2Switch:
Denes the output contact type.
NO – make contact or NC – break contact
K2 fn:
Determines the function of output K2.
(no) No function
(P min)
Lower than the valve position preset under
AlarmMinK2
(P max)
Exceeds the valve position preset under
AlarmMaxK2
(P min/max)
Lower or higher than the preset valve
positions
(W min)
Lower than the set value preset under
AlarmMinK2
(W max)
Exceeds the set value preset under
AlarmMaxK2
(W min/max) Lower or higher than the preset set value
(X min)
Lower than the actual value preset under
AlarmMinK2
(X max)
Exceeds the actual value preset under
AlarmMaxK2
(X min/max) Lower or higher than the preset actual value
(SSE min)
Lower than the system deviation preset
under AlarmMinK2
(SSE max)
Exceeds the system deviation preset under
AlarmMaxK2
(SSE min/
max)
Lower or higher than the preset actual value
Active Active if the positioner is in the OFF-mode
Error Error message
Warning Warning message
AlarmMinK2:
Sets the switch point in % under which output K2 is switched.
AlarmMaxK2:
Sets the switch point in % over which output K2 is switched
SSE2Time:
Determines the delay time for output K2 between error
recognition and error message for a permanent system
deviation.
