Gemu 1436 cPos - 4 SetCalibration

48 / 66
1436 cPos
Configuration
level
Display Function P1 P2 P3 P4 Factory settings
AlarmMaxK1
Switch point that switches after K1 is
exceeded
10.0 %
AlarmMinK1
Switch point that switches after K1 is
undershot
90.0 %
SSE1Time
Defines the delay time between error
recognition and error message to K1
5.0s
K2 Switch Defines the type of output K2 NO
K2 Fn Determines the function of output K2 no
AlarmMaxK2
Switch point that switches after K2 is
exceeded
10.0 %
AlarmMinK2
Switch point that switches after K2 is
undershot
90.0 %
SSE2Time
Defines the delay time between error
recognition and error message to K2
5.0s
Error Time
Determines the delay between error
recognition and error message
0.2s
ErrorAction
Function of the process valve if there is
an error message
Close
AnalogOut
Defines the function of the actual value
output
Poti
Configuration
level
Display Function P1 P2 P3 P4 Factory settings
4SetCalibration X-Direction
Determines the direction of the actual
value signal (rising/falling)
rise
W-Direction
Determines the direction of the set
value signal (rising/falling)
rise
W-Function The control curve is defined lin.
Y-Direction
Determines the direction of the process
controller output (rising/falling)
rise
PotDir
Defines the direction of the actual value
potentiometer of the valve
rise
OutMinPos Actual value output at 0/4 mA 0.0 %
OutMaxPos Actual value output at 20 mA 100.0 %
I Min W
Switch-off limit for cable break
recognition of the set value
3.5 mA
I Max W
Switch-off limit for excess current
recognition of the set value
20.5 mA
I Min X
Switch-off limit for cable break
recognition of the actual value
3.5 mA
I Max X
Switch-off limit for excess current
recognition of the actual value
20.5 mA
Scaling Switches the scaled display on OFF
Decimalpoint
Determines the number of digits
displayed after the decimal point
1
4 mA ≙
Defines the display which corresponds
to a 0/4mA signal
0 %
20 mA ≙
Defines the display which corresponds
to a 20mA signal
100 %
Configuration
level
Display Function P1 P2 P3 P4 Factory settings
5 Communication Fieldbus
Submenu for setting the fieldbus
address if available
X X X OFF
