1436 cPos
*X1andX3withProfibusDPversion:B-coded
** X2 with Profibus DP version: A-coded
Order example
1436 S02 Z 00M0 00M0
Type 1436
Fieldbus (code) S02
Accessory (code) Z
Connections X1* and X3*, A-coded (code) 00M0
Connection X2**, B-coded (code) 00M0
ConnectionX2**,B-coded Code
Without connector socket, with M12 protection cap 0000
M12 socket, B-coded, angle, without cable,
screw terminal 00M0
Y cable + 1 x M12 socket, B-coded, angle
without cable, screw terminal 00Y0
Y cable + M12 socket, B-coded, angle,
with 5 m PUR cable, 0.34 mm²
5 m Sub-D connecting cable 05Y0
Y cable + M12 socket, B-coded, angle,
with 10 m PUR cable, 0,34 mm²
10 m Sub-D connecting cable 10Y0
M12 socket, A-coded, angle, can be shielded,
without cable for Profibus DP
(only connection X1/X3, A-coded DPM0 available) DPM0
Connections X1* and X3*, A-coded Code
Without connector socket, with M12 protection cap 0000
M12 socket, A-coded, angle, without cable,
screw terminal 00M0
M12 socket, A-coded, angle,
with 5 m PUR cable, 0.34 mm² 05M0
M12 socket, A-coded, angle,
with 10 m PUR cable, 0.34 mm² 10M0
M12 socket, B-coded, angle, can be shielded,
M12 plug, B-coded, angle, can be shielded,
for Profibus DP (only connection X2,
B-coded DPM0 available) DPM0
Fieldbus Code
Connection kit S02
Accessory Code
Accessory Z
Order example
1436 PTAZ 01 090 000
Type 1436
Mounting kit (code) PTAZ
NAMUR size (code) 01
Measuring range (code) 090
Control air connector (code) 000
Mounting kit Code
Mounting kit - Quarter turn actuators PTAZ
Measuring range Code
Angle of rotation 90° 090
Control air connector Code
Without 000
NAMURsize Code
Hole spacing 80x30, shaft height 20 01
Hole spacing 80x30, shaft height 30 02
Hole spacing 130x30, shaft height 30 03
Hole spacing 130x30, shaft height 50 04
D Order data - Mounting kit for quarter turn actuators
C Order data - Connection kit
