57 / 66
1436 cPos
Order example
4232 000 Z 14 030 05M0 4001
Type 4232
Fieldbus 000
Accessory Z
Housing material (code) 14
Travel length (code) 030
Cable length (code) 05M0
Cable connection (code) 4001
Cable length Code
Length 2.0 m 02M0
Length 5.0 m 05M0
Others on request
Cable connection Code
M12 cable plug, straight, 5-pin, plastic 4001
Housing material Code
PP coated 05
Aluminium, black anodized 14
PVDF coated (suitable for High Purity) 20
Travel length Code
Potentiometer, 30 mm length 030
Potentiometer, 50 mm length 050
Potentiometer, 75 mm length 075
Note: The required travel length depends on the max. stroke of the
process valve and must be selected according to the mounting kits
listed.
Action Code
Single acting 1
Double acting 3
Flow rate Code
Q = 150 l/min 01
Q = 200 l/min 02
Q = 300 l/min (only single acting) 03
Device version Code
Positioner SA01
Positioner and process controller PA01
Options Code
Without 00
2 additional digital inputs 24 V DC 01
not possible with Profibus DP and DeviceNet version
Travel length Code
For external potentiometer, S01
M 12 connector, 5-pin
Order example
1436 000 Z 1 SA01 00 01 S01
Type 1436
Fieldbus (code) 000
Accessory Z
Action (code) 1
Device version (code) SA01
Options (code) 00
Flow rate (code) 01
Travel length (code) S01
Fieldbus Code
Without 000
DeviceNet DN
Profibus-DP DP
E Order data - Positioner for quarter turn actuators
F Order data - Travel sensor for linear actuators
