Gemu 1436 cPos - Page 60

60 / 66
1436 cPos
Order example
4231 000 Z XF 090 05M0 4001
Type 4231
Fieldbus 000
Accessory Z
Housing material (code) XF
Travel length (code) 090
Cable length (code) 05M0
Cable connection (code) 4001
Housing material Code
PAI XF
Travel length Code
Potentiometer, 90° 090
Cable connection Code
M12 cable plug, straight, 5-pin, plastic 4001
Cable length Code
Length 2.0 m 02M0
Length 5.0 m 05M0
Others on request
H Order data - Travel sensor for quarter turn actuator
Order example
4231 PTAZ 01 090 000
Type 4231
Mounting kit (code) PTAZ
NAMUR size (code) 01
Measuring range (code) 090
Control air connector (code) 000
Mounting kit Code
Mounting kit - Quarter turn actuators PTAZ
Measuring range Code
Angle of rotation 90° 090
Control air connector Code
Without 000
NAMURsize Code
Hole spacing 80x30, shaft height 20 01
Hole spacing 80x30, shaft height 30 02
Hole spacing 130x30, shaft height 30 03
Hole spacing 130x30, shaft height 50 04
I Order data - Travel sensor mounting kit
