Generac Power Systems Power Zone 410 - Dimensions

6 Owner’s Manual for Power Zone Gateway on PZ 410
General Information
Dimensions
Figure 2-2. Gateway Enclosure Dimensions
A 5.39 in (136.8 mm) D 2.0 in (51 mm)
B 2.89 in (73.3 mm) E 5.87 in (149 mm)
C 3.36 in (85.5 mm)
A
B
C
013866
013865
D
E
