Figure 3-21. Alternator Settings
System Detail Menu
The System Detail menu provides access to the alarm
logs, run logs and maintenance logs, contact information,
system notes, and maintenance notes.
Alarms and Warnings
The Alarms and Warnings screen displays only active
and present alarms and warnings.
A Warning (A) is considered active when the condition for
the warning is present. A Warning is low severity and
does not need to be acknowledged.
An Alarm (B) is considered active when an alarm condi-
tion is or was present, but the alarm has not yet been
acknowledged. An Alarm is high severity and must be
acknowledged. The generator will not operate when an
Alarm is present.
The list of active alarms and warnings is organized into
sections with controller alarms and warnings appearing
at the top of the list followed by alarms and warnings for
each transfer switch on the RS485 bus connected to the
Gateway AUX 485 port. Each section is preceded by a
row of orange text that describes the device that gener-
ated the alarm and a “Reset” button that can be used to
reset the alarms on that device. If the conditions for an
alarm or warning are still present, they will reappear as
new.
NOTE: Resetting controller alarms can result in the
generator starting if all other start conditions are active.
Alarms and Warnings are displayed with their respective
icons to the left followed by the word “Alarm” or “Warning”
followed by text describing the alarm.
The System Detail menu provides access to the Alarm
logs, 410 controller Run logs and Maintenance logs, TX
alarm and event logs, contact information, and system
notes and maintenance notes.
Figure 3-22. Reset Alarms, Warnings, and Maintenance
Alarm, Warning, Run, and Maintenance Logs
See Figure 3-23. The Alarm, Run, and Maintenance Log
screens show a chronological list of alarm, run and main-
tenance logs. See PZ 410 Controller Technical Manual
for list of possible alarms and warnings. Each alarm entry
is date and time stamped and shows the alarm text and
e-code of the parameter at the time it occurred. The list
filters to show alarms, warnings, run stop/starts, and
maintenance items. The list is paginated and up to 1,000
entries for each log type can be stored.
The log exports to USB devices connected to the USB
port of the Gateway or to the default download location of
your browser. There is also an option to email the log to a
list of recipients.
Download log to USB drive:
1. Select “Export”.
2. Select “USB”. A file named “log.csv” will be saved
to the storage device attached to the USB port.
Download log to remote computer:
1. Select “Export”.
2. Select “Download”. A file will be downloaded
through your browser.
Send log using email:
NOTE: This is only available if an email server has been
configured in the Communications Settings.
1. Select “Export”.
2. Select “Email”.
3. Enter email addresses separated by commas.
4. Select “Send”.
