4 Owner’s Manual for Power Zone Gateway on PZ 410
General Information
Specifications
NOTE: The Ethernet, RS-485, and USB cables should not be run in the same conduit or in the same wire grouping as
any high voltage or high current conductors.
NOTE: The RS-485 settings such as baud rate should be selected to be compatible with other components that are
connected to the RS-485 bus.
Environmental Specifications
Operating Temperature -40 °F (-40 °C) to 140 °F (60 °C)
Humidity 5% to 90% non-condensing
Enclosure UL Type IP2X
Weight 0.5 lbs
Power Supply Requirements
Power Supply Voltage 7 to 35 V (12 / 24 V nominal)
Power Supply Usage 0.5 A (maximum during power up)
Power Supply Cable 2 wires - 16 AWG recommended
Communication (Ethernet)
Number of Ports 1
Communication Link 4 wires minimum of 8 pin connector - 2 wire Receive and 2 wire Transmit
Communication Cable Cat5e – 2 twisted pairs
Maximum Cable Length 328 ft (100 m)
Baud Rate Auto-Detect 10/100 Mbps
Communication (RS-485)
Number of Ports 2
Communication Link 2 wires
Communication Cable 3 wires - shielded twisted pair and ground
Maximum Cable Length 4,000 ft (1,219 m)
Baud Rate Up to 115.2 kbps
Maximum Number of Devices 32
Protocol/Device Type Modbus / 1 Master and 1 Slave
Communication (USB)
Number of Ports 2
Connector Type A
USB version USB 1.1/2.0
Maximum Cable Length 16.5 ft (5 m)
Baud Rate 12 Mbps, 480 Mbps
LED
Number of LEDs 2
Color Red and green
