Model S4000T
3
3.0 Installation
3.1 Receipt of Equipment
All equipment shipped by General Monitors is pre-packed in shock absorbing
containers, which provide protection against physical damage (original containers
should be kept for future shipping or storage needs).
Shipping container contents should be carefully removed and checked against the
packing list. If any damage has occurred or there is any discrepancy in the order,
please notify General Monitors as soon as possible.
All correspondence with General Monitors must specify the equipment part number
and serial number.
Each unit is tested by the factory; however, a complete system check-out is
suggested upon initial installation to ensure system integrity.
WARNING - Installation and Maintenance must be carried out by suitably skilled and
competent personnel only.
WARNING - The Model S4000T Intelligent Sensor contains components which can
be damaged by static electricity. Special care must be taken when wiring the system
to ensure that only the connection points are touched.
3.2 Tools Required
1. “5mm” Allen head wrench to remove enclosure lid (included with gas detector).
2. Flat-head screwdriver maximum 3/16” (5 mm) width for terminal block connections
(included with gas detector).
3. Adjustable wrench for conduit or cable gland connections (not included).
