Model S4000T
43
Max. distance between the transmitter and sensor with one
way resistance of 10 ohms (20-Ohm loop):
AWG FEET METERS
14 3700 1125
16 2400 730
18 1500 460
20 1000 300
Figure 39 Sensor Cable Lengths
RFI/EMI Protection: Complies with EN50081-2, EN50082-2
European Union (EU) Approved Applications: PSU noise and ripple voltage 1.0Vpp
max. The customer supplied PSU must comply with IEC 1010-1, limiting current to
8A under Fault conditions, in order to comply with CE Marking requirements.
9.2.4 Environmental Specifications
Operating Temperature Range:
CSA/FM:
Electronics -40°F to 167°F (-40°C to +75°C)
Standard Sensor -65°F to 195°F (-55°C to +90°C)
CENELEC:
Electronics (T5) -40° F to 158° F (-40°C to +70°C)
Electronics (T6) -40° F to 104° F (-40°C to + 40°C)
Storage Temperature Range: -58°F to 185°F (-50°C to +85°C)
Operating Humidity Range: 5% to 100% RH, non-condensing
9.3 Approvals
• CSA and CENELEC Approved.
• FM, CE and ATEX Marking pending.
9.4 Spare Parts and Accessories
To order spare parts and/or accessories, please contact your nearest General
Monitors Representative or, General Monitors directly, and give the following
information:
• Part Number of Spare Part or Accessory
• Description of Spare Part or Accessory
• Quantity of Spare Part or Accessory
