8.3.2 Modbus Read Response Message
Byte
Modbus Range Referenced to S4000T
1
st
Slave Address 1-247* (Decimal) S4000T ID (Address)
2
nd
Function Code 03 Read Holding Registers
3
rd
Byte Count 02 No. Of Data Bytes
4
th
Data Hi 00-FF (Hex) S4000T Hi Byte Status Data
5
th
Data Lo 00-FF (Hex) S4000T Lo Byte Status Data
6
th
CRC Lo 00-FF (Hex) CRC Lo Byte
7
th
CRC Hi 00-FF (Hex) CRC Hi Byte
8.4 Modbus Write Command Protocol (Query/Response)
8.4.1 Modbus Write Query Message
Byte
Modbus Range Referenced to S4000T
1
st
Slave Address 1-247* (Decimal) S4000T ID (Address)
2
nd
Function Code 06 Preset Single Register
3
rd
Register Address Hi 00 Not Used by S4000T
4
th
Register Address Lo 00-FF (Hex) S4000T Commands
5
th
Preset Data Hi 00-FF (Hex) S4000T Hi Byte Command Data
6
th
Preset Data Lo 00-FF (Hex) S4000T Lo Byte Command Data
7
th
CRC Lo 00-FF (Hex) CRC Lo Byte
8
th
CRC Hi 00-FF (Hex) CRC Hi Byte
*NOTE - Address 0 is reserved for broadcast mode and will not be supported at this
time.
**NOTE - Start Address can be a maximum of 9999 Address Locations (0000-270E).
8.4.2 Modbus Write Response Message
Byte
Modbus Range Referenced to S4000T
1
st
Slave Address 1-247* (Decimal) S4000T ID (Address)
2
nd
Function Code 06 Preset Single Register
3
rd
Register Address Hi 00 Not Used by S4000T
4
th
Register Address Lo 00-FF (Hex) S4000T Commands
5
th
Preset Data Hi 00-FF (Hex) S4000T Hi Byte Command Data
6
th
Preset Data Lo 00-FF (Hex) S4000T Lo Byte Command Data
7
th
CRC Lo 00-FF (Hex) CRC Lo Byte
8
th
CRC Hi 00-FF (Hex) CRC Hi Byte
8.5 Function Codes Supported
Function Code 03 (Read Holding Registers) will be used to read status from the slave
unit.
Function Code 06 (Preset Single Register) will be used to write a command to the
slave unit.
