20
LUBRICATION
Proper lubrication is important for smooth operation and long life of each working part of the scooter. The major
lubrication points are indicated below：
NOTE：
1. Lubricate exposed parts which are subject to ruse with engine oil.
2. Before lubricating each part, clean off any rusty spots and wipe off any grease, oil dirt of grime.
WARNING：Be careful not to apply too much grease to the rear brake camshaft, otherwise brake slippage will result
from the presence of grease in brake drum.
steering stem bearing
front wheel bearing
engine bracket
rear brake camshaft
side stand
rear brake shaft and rear brake cable
speedometer cable and gear box
main stand
ΑA: lubrication
A
A
A
A
A
A
