Generic XOR 125 User Manual

80
REMOVE
□ Place the scooter on level ground.
□ Remove muffler.
□ Remove rear small fender.
□ Remove locknut and rear wheel.
□ Remove brake shoes.
INSPECTION
REAR RIM
Measure inner diameter of rear rim hub with micrometer, if
measured diameter exceeds 110.7, replace it with a new one.
Brake shoes
Check the brake shoe and decide whether it should be replaced or not from the thickness of the brake shoe
lining.
Service limit：2.5mm(0.09in)
