79

REAR WHEEL AND BRAKE

1. Tire 130/70-12

2. rear rim assy.

3. brake pad kit

assy.

4. brake pad kit

spring

5. rear brake

tension

6. rear indicator

7. anti-dust cover

8. rear brake

camshaft

9. bolt M6Χ30

10. valve

11. nut M16Χ1.5

12. rear brake arm

13. valve ca

p
