77
Reassembly and remounting
reassemble and remount the steering stem, handlebar and front fork in the
reverse order of disassembly andremoval, and also carry out the
following steps.
Install the right left suspension arms.
Steel ball
Apply grease when installing the upper and lower steel balls.
QTY：upper ：21
lower ：21
Tighten the steering outer race with special tool, then extrude it
1/8-1/4round.
NOTE：adjustment will vary from scooter to scooter. Be sure
that the steering turns smoothly and easily, left to right.
□ install a locknut by installing locknut and anti-dust cover
□ screw locknut with special tool, and adjust front fork bearing
to get smooth turning.
