Generic XOR 125 - STEERING STEM AND FRONT SUSPENSION INSPECTION; Steering Stem Inspection

97 pages

Save Page as PDF

To Next Page

To Previous Page

INSPECTION

□ inspect the removed parts for the following abnormalities.

 bearing race wear and brinelling.

 Worn and damaged steel balls

 Distortion of steering stem or handlebar.

□ Inspect the suspension for damage
