75
□ remove disc brake system by unscrewing tightening bolt.
□ remove handle by removing tightening bolt
□ unscrew locknut with special tool
□ remove fornt fork assy. by removing upper outer steel bowl
NOTE:
Not drop the steering stem balls.
□ remove front fork
□ remove bearing lower race by chisel.
□ Remove steel balls.
Number of steel balls：
Upper：21
lower：21
□ remove the upper and lower bearing inner races with a appropriate bar
