• Output Frequency Lower Limit – Provides adjustment of output frequency lower

limit (0.0 - 200 Hz).

• Acceleration and Deceleration Time – Provides adjustment of acceleration and

deceleration time (0.1 - 999 seconds).

• Operates 60 Hz and 50 Hz Motors – Provides tailoring of the drive for 60 Hz or 50

Hz motors (factory set for 60 Hz motors).

• Analog Output Voltage – Provides connections for an analog voltage (0 - 10 V DC)

proportional to the output frequency.

• Preset Volts/Hz Curves with Program Modification – Used to tailor the drive for

constant torque, high starting torque, or variable torque (HVAC) applications.

• Approvals – UL Listed (USA and Canada), CE, C-tick (N10980), ISO-9002.

PROTECTION FEATURES (Fault Codes are Displayed)

See Table 17, on pages 49 and 50.

• Overvoltage and Undervoltage Protection – Shuts down the drive if the AC line

voltage goes above or below the operating range.

• Regeneration Protection – Eliminates tripping due to bus overvoltage caused by

rapid deceleration of high inertial loads.

• Stall Protection – Prevents the motor from stalling during startup of high inertial

loads.

• Short Circuit Protection – Shuts down the drive if a short circuit occurs at the motor

(phase-to-phase or phase-to-ground).

• Electronic Motor Overload Protection (I

t) – Prevents motor burnout and elimi-

nates nuisance tripping due to overload.

• Overtemperature Protection – Shuts down the drive if the temperature exceeds

safe limits.

OPTIONAL ACCESSORIES (See Section X, on page 51.)

• Class B Residential Standard RFI Filter – Provides noise suppression for Class B

Residential Standard requirements (CE Directive 89/336/EEC).

Note: All models are available with a built-in Class A Industrial Standard RFI

Filter. Contact Sales Department.

• Brake Resistor Kit – Provides rapid stopping of the drive. Available for Models

KBE2-2202, 2203, 4301, 4302, 4303.

• DIN Rail Mounting Kit

• DownLoad Module™ (DLM) – Uploads and downloads drive programs.

• Drive-Link™ Software – Provides PC communications to facilitate programming.

Uses Windows® 95/98/2000/ME/XP/NT.

Sec. I – Introduction (Cont.)

Genesis KBE2 User Manual
