b. If the drive is in Stop Mode, press the ▲ key to increase the set
frequency.
c. If a function number is displayed, press the ▲ key to increase the func-
tion number to the next higher number.
d. If a function value or code is displayed, press the ▲ key to increase the
function value or code setting.
5. ▼/RESET Key – The ▼ key is used to decrease frequency, decrease to
the next lower function number, decrease the function value or code set-
ting, or reset the drive after a fault has occurred. Pressing the ▼/RESET
key once will cause the display to decrease by 1 unit. Maintaining pressure
on the ▼/RESET key will cause the display units to decrease rapidly.
a. If the drive is in Run Mode, press the ▼/RESET key to decrease the
frequency.
b. If the drive is in Stop Mode, press the ▼/RESET key to decrease the
set frequency.
c. If a function number is displayed, press the ▼/RESET key to decrease
the function number to the next lower number.
d. If a function value or code is displayed, press the ▼/RESET key to
decrease the function value or code setting.
e. If a fault has occurred, press the ▼/RESET key to reset the drive.
6. DATA/ENT Key – The DATA/ENT key is used to display or enter a func-
tion’s setting.
a. If the desired function number is displayed, press the DATA/ENT key to
display the function value or code.
b. If the desired function value or code is displayed, press the DATA/ENT
key to program the function to the new value or code. “End” will be
momentarily displayed.
B. Digital Keypad Operation – Examples of basic keypad operations are
described below.
Note: When the DSP/FUN key is pressed, the last function number will be dis-
played. If the AC line is interrupted for more than 2 seconds, then “F00” will
be displayed when the DSP/FUN key is pressed.
1. Setting Drive Output Frequency Using the Keypad – The drive is factory
set to run at 5.00 Hz when the drive is in the Run Mode. (Press the
RUN/STOP Key to start or stop the drive.) See Figure 14 on page 29.
a. To change the Set Frequency (drive in Stop Mode):
1. Press the ▲ or ▼ key until the desired frequency is displayed.
