Drive Is Shown with Optional Power On/Off Switch, Forward-Stop-Reverse Switch, and Main Speed Potentiometer.
11.65
10.85
8.25
9.15
275
295
210
232
Drive Depth with Optional Switches:
Drive Depth without Optional Switches:
8.35
212
181
7.15
RESET
RUN
STOP
DATA
ENT
DSP
FUN
15
FIGURE 1D – MECHANICAL SPECIFICATIONS (Inches/mm)
for Models KBE2-2202-4, 2203-4, 4301-4, 4302-4, 4303-4 (Pkg. C1)
Sec. II – Mounting Inst. (Cont.)
