33
To change the setting of F23 from “000” to “001”:
1. The drive must be in Stop Mode (press the RUN/STOP key). The
set frequency will flash on the display.
2. Press the DSP/FUN key to display function number.
3. Press the ▲ or ▼/RESET key until “F23” is displayed.
4. Press the DATA/ENT key. The function code will be displayed.
Factory setting is “000” [Enable Auto Restart].
5. Press the ▲ key until “001” [Disable Auto Restart] is displayed.
6. Press DSP/FUN key to return to the frequency display or press the
▲ or ▼/RESET key to change to another function number.
b. Automatic Restart for All Faults Except AC Power Loss* – If the appli-
cation requires that the drive automatically restart after a fault has cleared,
except for an AC power loss, Function F24 must be set as follows. See
Table 13. (Note: F23 and F24 are both factory set to “000”.)
The faults that are automatically reset are indicated by the following
codes: OCS, OCA, OCC, OCd, OCb, OUV, LUC, OHC
To change the setting of F24 from “000” to “005”:
1. The drive must be in Stop Mode (press the RUN/STOP key).
2. Press the DSP/FUN key to display function number.
3. Press the ▲ or ▼/RESET key until “F24” is displayed.
4. Press the DATA/ENT key. The number of restart attempts will be
displayed. Factory setting is “000”.
5. Press the ▲ key until “005” (5-restart attempts) is displayed.
6. Press DSP/FUN key to return to the frequency display or press the
▲ or ▼/RESET key to change to another function number.
* The drive will restart with a momentary power loss of less than 2 sec-
onds (F23 set to “000”).
Function
Number
Function Description Code/Value Description of Code/Value
F23
Auto Restart After a Fault
Has Cleared
000
(Factory Setting)
Enable Auto Restart After a
Fault Has Cleared
F24
Number of Auto Restart
Attempts
005
(Factory Setting is “000”)
Five Auto Restart attempts
F28 Automatic AC Line Start
001
(Factory Setting)
Disable Automatic AC Line Start
TABLE 13 – FUNCTIONS F23, F24, F28 SET FOR AUTOMATIC RESTART
FOR ALL FAULTS EXCEPT AC POWER LOSS
Sec. VIII – Drive Operation (Cont.)
