36
WARNING! The Stop contact is never to be used as a Safety Disconnect
since it is not fail-safe. Use only the AC line for this purpose.
To change the setting of F03 to Run/Stop-Forward/Reverse:
a. The drive must be in Stop Mode (press the RUN/STOP key).
b. Press the DSP/FUN key to display function number.
c. Press the ▲ or ▼/RESET key until “F03” is displayed.
d. Press the DATA/ENT key. The function code will be displayed. Factory
setting is “000” [Forward/Stop-Reverse/Stop].
e. Press the ▲ or ▼/RESET key until code “001” [Run/Stop –
Forward/Reverse] is displayed.
f. Press the DSP/FUN key to return to the frequency display or press the
▲ or ▼/RESET key to change to another function number.
7. Setting F20 for Preset Speed #2 – Multifunction Input Terminal 7 is used
to set various functions for operating the drive. F20 is factory set to “005”
[Reset] to reset the drive after a fault has cleared. See Preset Speed oper-
ation in Section V-B-5, on page 23.
To change the setting of F20 to Preset Speed #2:
a. The drive must be in Stop Mode (press the RUN/STOP key).
b. Press the DSP/FUN key to display function number.
c. Press the ▲ or ▼/RESET key until “F20” is displayed.
d. Press the DATA/ENT key. The function setting will be displayed (factory
setting is “005” [Reset]).
e. Press the ▲ or ▼/RESET key until code “006” [Preset Speed #2] is dis-
played.
f. Press the DSP/FUN key to return to the frequency display or press the
▲ or ▼/RESET key to change to another function number.
Note: F20 can be used to set the following functions: Jog (“001”),
Preset Speed #1 (“002”), Rapid Stop (“003”), Coast-to-Stop (“004”),
Reset (“005”) (factory setting), and Preset Speed #2 (“006”).
D. Programmable Functions (Summary List) – All functions have been factory
set, as shown in Table 15, on pages 37 and 38. See Section IX, on page 39,
for a detailed description of each function.
