54
H. AC Load Reactor – Eliminates false tripping when motor wires exceed 100
feet (30 m). See Table 22, for the recommended AC Load Reactor. AC Load
Reactors can be purchased from ACME, MTE, and TCI.
Note: The voltage rating of the AC Load Reactor must be equal or greater than
the drive’s nominal AC line input voltage rating.
Drive Model
AC Line
Input Phase(s)
AC Line Reactor Rating
Volts AC Amps AC mH
KBE2-2125 1 230 3 7
KBE2-2150 1 230 5.2 4.2
KBE2-2101 1 230 9.4 2.1
KBE2-2202
1 230 19 1.1
3* 230 11 1.1
KBE2-2203
1 230 27 0.71
3* 230 20 0.71
KBE2-4301 3* 460 2.5 8.4
KBE2-4302 3* 460 5 4.2
KBE2-4303 3* 460 7.5 3.6
G. AC Line Reactor – Eliminates erratic operation or tripping due to a noisy or
unstable AC power source. The following are some typical problems associat-
ed with an AC line which will require the addition of a line reactor: multiple drives
on the same line, solenoids, power factor correction capacitors and machinery
switching “on” and “off”. See Table 21 for the recommended AC Line Reactor.
AC Line Reactors can be purchased from ACME, MTE, and TCI.
TABLE 21 – RECOMMENDED AC LINE REACTOR SELECTIOIN CHART
*Note: For 3-phase AC line inputs, a 3-phase reactor or three 1-phase reactors must be used.
Motor Rating
(Nominal)
(Amps AC)
AC Load Reactor Rating
Amps AC mH
2 2 11
3 3 7.4
3.4 4 5.5
4.8 6 3.7
7.6 8 2.8
11 12 1.8
14 16 1.4
21 25 0.88
27 27 0.82
34 35 0.63
40 45 0.49
TABLE 22 – RECOMMENDED 3-PHASE AC LOAD REACTOR SELECTION CHART
Sec. X – Optional Accessories (Cont.)
