Genesis KBE2 User Manual

18
1φ AC
Line Input
Ground
(Earth)
L1 L2 T1 T2 T3
3φ AC
Induction Motor
FIGURE 3A – POWER CONNECTIONS for PKG. A and PKG. C
MODELS with 1φ AC LINE INPUT
PRL2L1(L) L3(N) T1 T2 T3
3φ AC
Induction Motor
Optional
Brake Resistor
*For 1φ AC line input, use Terminals L1(L) and L3(N)
3φ AC*
Line Input
Ground
(Earth)
FIGURE 3B – POWER CONNECTIONS for PKG. B
MODELS with 1φ and 3φ AC LINE INPUT
FIGURE 3C – POWER CONNECTIONS for PKG. C1
MODELS (NEMA-4) with 1φ and 3φ AC LINE INPUT
Brake Resistor
Optional
3φ AC
Induction Motor
*For 1φ AC Line Input,
use Terminals L1(L) and L2(N)
AC Line Input*
T1 T2 PT3 R
Chassis
(Earth)
Ground
Chassis
230VAC Models
460VAC Models
L3L1(L) L2(N)
L1 L2 L3
TM3
TM1
