28142 Rev 15 TECHNICAL SPECIFICATIONS
Gentherm Global Power Technologies Page 7
Power output
Power Ratings
20º C, 750 m above sea level
195 Watts @ 12 Volts
178 Watts @ 24 Volts
Electrical
Voltage Adjustment
12 V 12–18 Volts
24 V 24–30 Volts
Reverse Current Protection Yes
Output
Terminal block which accepts up to 8 AWG wire.
Opening for 3/4” conduit in the base of the cabinet
Fuel
Natural Gas
19.7 m
3
/day (698 ft
3
/day) of Std. 1000 BTU/ SCF
(37.7 MJ/Sm
3
) gas
Propane 28.0 L/day (7.4 gal/day)
Maximum Supply Pressure 345 kPa (50 PSI)
Minimum Supply Pressure 165 kPa (24 PSI)
Fuel Connection 1/4” Female NPT
Environmental
Ambient Operating Temperature
Continuously Running TEG
Max. 45º C (115º F) Min. -40º C (-40 ºF)
Operating Conditions Unsheltered Operation
Materials of Construction
Cabinet 304 Stainless Steel
Cooling Type Natural Convection
Fuel System Brass, Aluminum & Stainless Steel
