28142 Rev 15 INSTALLATION
Gentherm Global Power Technologies Page 22
5 INSTALLATION
This section provides installation instructions for the Model 5220 Thermoelectric Generator.
The installation must conform with local codes or, in the absence of local codes, with the
CSA-B149.1 Natural Gas and Propane Installation Code and CSA-B149.2: Propane Storage
and Handling. The TEG must be kept clear and free from combustible materials, gasoline and
other flammable vapours and liquids. Maintain 900 mm (36 in.) minimum clearances from
combustible construction to the top, sides and back, and install over a non-combustible floor.
Do not use this appliance if any part has been under water. Immediately call a qualified
service technician to inspect the appliance and to replace any part of the control system and
any gas control which has been underwater.
The TEG when installed must be electrically grounded in accordance with local codes, or in
the absence of local codes, with the applicable provisions of the Canadian Electrical Code CSA
C22.1. A grounding lug is provided on the interior of the cabinet for this purpose.
CAUTION!
Do not wire TEG through a stand-
alone solar charge
controller. This may cause internal damage to the
TEG.
The following tools are required for installing the TEG:
• 1 - DC Voltmeter, accurate to ±0.1 V.
• 2 - Adjustable Wrenches, that will open to 16 mm (5/8 in.)
• 1 - Screwdriver, flat-head
• 1 - Screwdriver, Phillips
• 4 - Bolts & nuts, 1/4-inch diameter, for mounting
Unpack the TEG from its shipping crate. Keep the crate until the TEG is operational. Locate
and identify the following items that were shipped with the 5220 TEG:
• 1 - Fin Duct
• 1 - Cover Plate
• 1 – Manual Shutoff Valve
• 1 – Wind Scoop (leg assembly or pole mount)
• 1 - Thread Sealing Compound
• 17 - Screws, #8 32 × 1/4 in. long, one spare
• 17 - Washers, #8 External Lock, one spare
