28142 Rev 15 INSTALLATION
Gentherm Global Power Technologies Page 30
TEG Wiring Interconnection
Wire the L/C directly to the TEG using the following procedure:
1. Feed the wires from the L/C into the TEG cabinet through the hole provided.
NOTE:
If remotely mounting the L/C, size the interconnecting wires between the
generator and the L/C for 17 A, and use no less than AWG no. 10.
2. Before connecting the input or output wires to the TEG terminal block, ensure that
the selector switch setting (Figure 7) is correct for the required voltage and model of
the TEG.
3. Connect the L/C wires to TB-1 as per Figure 14.
The CP interface is normally shipped ready for operation, attached to the TEG. If it was
shipped separately, install it as follows:
NOTE:
Before installing, inspect the electronics for obvious damage
components and advise
Gentherm Global Power Technologies (GPT) if
damage is found.
Attaching the CP Interface System to TEG
The standard mounting location is on the left side (looking at the front of the TEG) of the
generator cabinet. To attach the CP interface system, remove the four nuts and lock washers
provided and bolt it to the outside of the TEG, see Figure 15.
