Box Camera
5
1
No. Name Description
7 Auto Iris Connector
Plug the iris control cable to the connector.
Note that Auto Iris Connector is not
functional in GV-BX130D-1,
GV-BX140DW and GV-BX520D-0.
8 DC 12V Port Connects to power.
9 LAN / PoE Connects to a 10/100 Ethernet or PoE.
10 Default Resets all configurations to factory default.
See 12. Restoring to Default Settings later
in the Quick Start Guide.
11 Light Sensor Detects light to switch between day and
night mode.
12 Focus Screw Adjusts the focus of the camera.
13 Iris Screw Adjusts the iris of the camera
14 Microphone Records the sounds.
15 Zoom Screw Adjusts the zoom of the camera
16 Status LED Turns on when the unit is ready for use.
