24
3.2 Overview
GV-MFD110
321 4 5
7
6
No. Name Description
1 Default Button
Resets the GV-MFD110 to factory default.
See 12. Restoring to Default Settings later
in the Quick Start Guide.
2 Lens Rotates the les right/left to adjust focus.
3 Focus Screw Loosens the screw to adjust the focus.
4 Tilt Screw Loosens the screw to adjust the tilt angle.
5 Built-In Microphone Provides one-way audio.
6 Pan Screw Loosen the screw to pan.
7 Network/PoE
Connection
Connects the Network cable for power and
Ethernet connection.
