Mini Fixed & Rugged Dome
25
3
GV-MFD120 / 130 / 220 / 320 / 520
1 2 3
4
5
7
6
No. Name Description
1 Default Button
Resets the camera to factory default. See
12. Restoring to Default Settings later in
the Quick Start Guide.
2 Lens Receives image inputs.
3 Tilt Screw Loosens the screw to adjust tilt angle.
4 Built-In Microphone Provides one-way audio.
5 Pan Screw Loosens the screw to pan.
6 LED Indicators See LED Indicators below.
7 Memory Card Slot
Inserts a micro SD / SDHC / SDXC card to
store recording data.
To Next Page
