Vandal Proof IP Dome
61
5
5.4.2 Connecting the Power Cable
There are two ways to supply power to the camera:
• Use a Power over Ethernet (PoE) adapter to connect the camera to
the network, and the power will be provided at the same time.
• Use the supplied Terminal Block and power adapter. Follow the steps
below to connect the Terminal Block and the power adapter.
1. Insert the thin black wire of the Vandal Proof IP Dome to the left pin
and the red wire to the right pin.
2. Connect the DC 12V Power Adapter to the Terminal Block.
DC 12V Power Adaptor
Terminal Block
To Next Page
