GeoVision GV-FD120D Quick Start Guide

16
2.2 Overview
1 2
3
4
5
7 6
Note: The Iris Screw (no. 7) is only available in GV-BX520D-E.
No. Name Description
1 Silica gel bag Desiccant that keeps the camera housing dry.
2 IR power plug Supplies power to the built-in IR LEDs.
3 Focus Screw Adjusts the focus of the camera.
4 Module screw Holds the module in place.
5 Status LED Turns on when the unit is ready for use.
6 Zoom Screw Adjusts the zoom of the camera.
7 Iris Screw Adjusts the iris of the camera.

GeoVision GV-FD120D Specifications

General

Brand	GeoVision
Model	GV-FD120D
Category	Security Camera
Language	English
