22
3. Connect the camera’s cable to the GV-PA481 PoE adapter as
illustrated below. The power and network will be supplied
simultaneously.
Ethernet Cable
PoE
GV-BX-E
Rear Panel
Power Hub/Router
POWER &
DATA OUT
DATA IN
4. The status LED of the camera will be on.
Note: For using the IR Arctic Box Camera, ensure that you:
1. enable the IR LED function on the Web interface after loading the
default settings.
2. disable the status LED to reduce reflection when a green light
spot appears on the live view.
For details, see Notice for Using the IR Arctic Box Camera section, IR
Arctic Box Camera Chapter, GV-IPCam H.264 User’s Manual on the
software CD.
