Bullet Camera (Part I)
8
8.3 Installation
The Bullet Camera is designed for outdoor use and can be mounted on
ceiling and wall.
1. Slide the cable clamp to the camera base.
Cable Clamp
2. Install the Bullet Camera to the wall / ceiling.
3. Remove the protection sticker from the camera’s cover.
4. Connect the power, network and other cables to the camera. See 8.4
Connecting the Camera in the Quick Start Guide.
5. Access the live view. See 21.2 Accessing the Live View in the Quick
Start Guide.
6. Adjust the angles of the camera body based on the live view. Three
shafts can be adjusted. For details, see 8.3.1 Adjusting the Angles in
the Quick Start Guide.
71
