1.3.2 Infrared Illuminators (Optional)
1. Connect the infrared illuminator to the terminal block on the camera.
See I/O Terminal Block, Box Camera Chapter, GV-IPCAM H.264
Hardware Manual on the Software DVD.
2. Access the Web interface of the camera.
3. Select Video and Motion, select Video Settings, select Streaming 1
and set the IR Check Function setting to Trigger by Input.
4. Click Apply.
For details on the Trigger by Input function, see the Video Settings section,
Administrator Mode Chapter in the GV-IPCAM H.264 Firmware Manual in
the Software DVD.
8
