Target Mini Fixed Dome
6
4. Thread the power and / or network cable(s) through the oval-shaped
hole or the cable opening on the side, and connect the camera to
network and power. For details, see 6.4 Connecting the Camera.
5. Secure the Target Mini Fixed Dome to the ceiling or the wall with the
self-tapping screws.
6. Access the live view. For details, see 21.2 Accessing the Live View in
the Quick Start Guide.
7. Loosen the tile screw and pan screw, adjust the angles based on the
live view as needed, and tighten the screws again.
Pan Screw
Tilt Screw
8. Adjust image clarity using the GV-IP Device Utility program. For details,
see 21.3 Adjusting Image Clarity in the Quick Start Guide.
9. Place the housing cover back and turn to secure it.
57
