22
CHAPTER 4
Operating the EDGE 2
problem, reset the EDGE 2 to the factory settings and try your job again.
If you still have a problem, contact the Gerber Field Service Department.
To reset to factory settings
1
Turn off the EDGE 2.
2
Press and hold RESET.
3
Turn on the EDGE 2 and keep RESET pressed until you see:
4
Release RESET. The EDGE 2 is reset to factory settings.
5
Press any key to delete the “factory defaults” portion of the display.
Matching a print created on an older EDGE
If it is necessary to match a job printed on an older EDGE, use the spool
file (SPL) created for the older print. The EDGE 2 will recognize it as an
old file and use the same speed and print settings that were used on the
older EDGE.
Note: It is important to print the SPL file. If you go all the way back to the PLT
file and use it, the job will re-render as an EDGE 2 job.
OFFLINE
FACTORY DEFAULTS
