Gerhardt S Series - Fill Cup Dispenser; Filling the Lid Dispenser

Transport, installation and commissioning
37
5.3.5 Fill cup dispenser
Cup diameter
Cup capacity
70 mm
approx. 750 cups
80 mm
approx. 500 cups
Method
1. Unlock and open the automatic door with the key.
2. Support the top of the cup dispenser with one hand.
3. Grasp the cup dispenser by the handle with one hand, lift it
slightly and pull it slowly.
4. Tilt the cup dispenser until it audibly clicks into place.
5. Remove cover.
Method
1. Unpack the cup rack according to the hygiene concept.
2. Check cup for damage.
3. Check cup for correct size.
4. Fill the shafts with suitable cups.
Method
1. Reattach the sealing cap.
2. Place the cup dispenser vertically.
3. Press the cup dispenser into the initial position until the cup
dispenser audibly engages.
4. Select Service menu > Function tests > Cup mechanism.
 The machine dispenses a cup.
5. Close the automatic door and lock it with the key.
5.3.6 Filling the lid dispenser
Method
1. Unlock and open the automatic door with the key.
2. Swing the lid dispenser out to the right.
3. Turn the drum to the right until the recess at the top is
exactly over the filling tube.
Unlocking the cup dispenser
Fill cup dispenser
Locking the cup dispenser
Unlocking the lid dispenser
