Page 16 av 64
Line Sub-
line
Parameter Basic
setting
Setting range
Authorization
Lines no 50-57: Tank and water
50 - Tank level at rest 2 1=Empty tank, 2=Level B,
3= Level C
CD
51 - Water type, filling at rest 1 1 = cold, 2 = hot, 3 = cold and hot CD
52 - Mix ratio 50 0-100 % cold water CD
53 01 Type of rim flushing 1 0=None, 1=Internal CD
54 - Addition of softened water 0 0=none, 1=internal CD
55 - Time for soft water 5 0-99 seconds CD
56 - Flushing time cooling 0 0.0-99.9 seconds
replaces line 45 in Eprom ver. 1.21
CD
57 01 Flushing time in the instruction
“Pulsed flushing to level”
1.5 0.0-99.9 seconds CD
57 02 Pause time in indication
“Pulsed flushing to level”
1.0 0.0-99.9 seconds CD
57 03 Pulses in the instruction
“Pulsed flushing to level”
5 0.0-99.9 seconds CD
Lines 60-63: Fault statistics
60 - Time of fault 0-9999 seconds -
61 - Instruction for last fault 0=not in flushing program,
1-999=program line
-
62 - Counter, total number of faults 0-9999 -
63 01 Counter for fault code F1 0-99 faults CD
63 nn Counter for fault codes Fnn 0-99 faults CD
Lines 70-74: Program statistics
70 - Max disinfection temperature 80-99 ˚C -
71 - Program time, last process 0-9999 seconds -
72 - Program time, total 0-99999 seconds -
73 - Counter for number of processes 0-99999 -
74 01 Counter, program 1 0-9999 CD
74 nn Counter, program nn 0-9999 CD
Line 80: Function test
80 - Display test 1=activate LEDs and display CD
81 01 Read input 1 (max 12) 0=off, 1=on -
81 nn Read input nn 0=off, 1=on -
82 01 Control, outputs 1 (max. 16) 0 = off, 1 = on CD
82 nn Modulation output. nn 0=off, 1=on CD
83 01 Read temperature C/F 0-250 ˚C/32-302 ˚F -
83 02 Reading temperature C/F independent 0-250 ˚C/32-302 ˚F -
85 - Save config. in flash
86 - Load config. from flash
87 - Calibrate AD
88 - Calibrate independent AD
