GFA TS 971 - Overview of Control

Overview of control
T
2.1 2.3 2.5 2.2 2.4
20.1
1.8 1.9
ANT
GN D
20.2 20.3
21.1
21.2 21.3
F1 = 1,6A t
V1
MOTDES
S11
S12
S13
X20X21
X3
X2
X4 X5 X
X6
X7 X8
F1
UBS S
X1
DES Socket X 24 V mains supply, external devices
F1 Micro-fuse 1.6 A time-lag X1 Mains supply
MOT Motor socket
S Selector switch
X2
Safety edge system and
door safety switch
S11 OPEN push-button X3 Emergency stop button
S12 STOP push-button X4 Automatic closing On/Off
S13 CLOSE push-button X5 Control device, external three push-button
T Internal aerial, 434 MHz X6 Through / reflective photo cell
UBS Universal command sensor socket X7 External radio receiver, pull switch
V1 Display X8 Intermediate stop On/Off
X20 Potential-free relay contact 1
X21 Potential-free relay contact 2
