11 Status display
Faults
Faults
Display: "F" and code
Status
code
Fault description Measures for fault correction
Terminals X2.1 – X2.2 are open.
Slack-rope/pass-door contact is open.
Check door safety switch.
Check whether the connection cable is
connected.
Safety circuit is opened.
Emergency manual operation has been
activated.
Thermal protection of the motor has tripped.
Check emergency manual operation.
Check for overload or stalling of the drive unit.
Terminals X3.1 – X3.2 are open.
Emergency stop has been activated.
Check emergency stop.
Check whether the connection cable is
connected.
Faulty “WSD” radio transmission.
Change "WSD" door module batteries.
Switch control off and on.
Faulty "Entry sense" switch.
Contact resistances are too high.
Faulty entry sense installation.
Open and close pass-door.
Check resistance.
Check pass-door installation.
Entry sense input
(X2.1 – X2.2) faulty.
Switch control off and on.
Replace control if necessary.
"WSD" door module batteries are too low. Change "WSD" door module batteries.
No safety edge is detected.
Check the wiring of the safety edge system.
Check whether the "WSD" is correctly
functioning.
Terminals X6.1 – X6.2 are open.
Photo cell has been activated.
Check alignment of the photo cell.
Check connection cable.
Replace photo cell if necessary.
Maximum number of reversing movements for
door through safety edge system activation has
been reached.
Onl
with automatic closin
Obstacles in the door travel path.
Check whether the safety edge system is
correctly functioning.
