X8: Input, intermediate stop On/Off
Connect a switch to terminals X8/1 and X8/2 to activate and deactivate the intermediate stop.
Programme the intermediate stop position via menu “1.6”.
With an OPEN command, the door moves to the stored door position. When the intermediate
stop function is deactivated, the door can move back to the OPEN final limit position.
Intermediate stop function
Menu "2.9":
Function Intermediate stop
"1" All command inputs
"2"
Intermediate stop via X7 pull switch and internal radio receiver;
OPEN final limit position via all other control devices
"3"
Intermediate stop via external X5 control device and internal control
device
OPEN final limit position via all other control devices
Note!
Double command with functions "2" and "3": Priority is given to OPEN final limit
position, independent of command sequence
