Door positions
Door positions
OPEN final limit position, coarse correction
OPEN/CLOSE door movement
CLOSE final limit position, coarse correction
OPEN/CLOSE door movement
OPEN final limit position, fine correction
Without door movement,
[ + ] correct in OPEN
[ – ] correct in CLOSE
CLOSE final limit position, fine correction
Without door movement,
[ + ] correct in OPEN
[ – ] correct in CLOSE
Pre-limit safety edge, fine correction
Without door movement,
[ + ] correct in OPEN
[ – ] correct in CLOSE
Intermediate stop
OPEN/CLOSE door movement
Adjust position of relay 1 switching point
Select relay function via menu 2.7
OPEN/CLOSE door movement
Adjust position of relay 2 switching point
Select relay function via menu 2.8
OPEN/CLOSE door movement
