Reversing function
Menu "2.5":
Limiting of the number of reversing movements following safety edge system activations via
automatic closing.
If the set value is exceeded, automatic closing is deactivated and the "F2.2" fault indication is
displayed.
Note!
To reset fault "F2.2": Move to CLOSE final limit position
Integrated "WSD" wireless safety device
For evaluating the safety edge system and/or door safety switch without a spiral cable. For
initial operation, see "Teach-in of WSD door module".
Attention – Damage to components!
▶ We recommend providing further protection (protective cover) for the use in car
wash facilities
Water additives (e.g. softening agents, surfactants)
lead to brittle and cracked gaskets
▶ Keep the lines short from the "WSD" junction box to plug connections and
terminals
▶ Avoid installing the lines directly above the receiver board
▶ Avoid bending the aerial
▶ Carefully close the cover
Usable safety devices
Safety edge systems
8K2 resistor evaluation
Optical safety edge system
(universal or low-power sensors only)
Door safety switch
Slack-rope or pass-door switch
Crash switch with NC contact
