Note!
▶ For a description of the safety device and relevant adjustment procedures see X2
Crash switch function as NO contact is hidden
If the battery is low, fault indication "F1.9" appears and there is a changeover to
the "hold-to-run" door operating mode
Battery is fully discharged: Fault indication "F1.6" is displayed and door movement
is not possible
▶ When performing annual maintenance tasks involving the door system, replace
the "WSD" battery as a precautionary measure
Menu "9.6":
Alternating display of "WSD" statuses including
Version
Type of safety edge system
"0.0." = none
"0.1." = 1k2
"0.2." = 8k2
"0.3." = optic
Door safety switch
"0.0." = inactive
"0.1." = active
Battery voltage
Assigned / selected communication channel
Signal quality ranging from 0% - 99%
