Symbol Explanation
Prompt: Setting via OPEN/CLOSE built in push button,
open push button: Value upwards; CLOSE button: Value downwards
Prompt: Press stop button once via built in push button
Prompt: Save,
press stop button once via built in push button
Prompt: Save,
press stop button for three seconds via built in push button
Prompt: Reset the control,
press stop button for three seconds via built in push button
Prompt: Move to door positions
Prompt: Move to door positions for OPEN limit switch
Prompt: Move to pre-limit
Prompt: Move to door positions for CLOSE limit switch
